the pinnacle

OF TECHNOLOGY

Discover our marine engine games from 10Kw (20hp) to 70Kw (140hp)

Discover

Our Ranges

of Electric Motors

Discover our permanent magnet synchronous motors, from 3kW to 200kW

Discover

Découvrir

Our Ranges

of Lead / Lithium Charger

Discover our Lead and Lithium battery chargers from 3.7V to 144V

Discover

OUR RANGES POWERBOX

Variable speed drives

Electronic speed variators for electric motors

Discover

Online laser cutting service

Design Service

Cutting of engine support, battery trunk, coupling and other cutting adapted to your needs.

NEWSPRODUCTS

Orange flexible multistrand cable 450V/750V

Sale!

Quick view

Orange flexible multistrand cable 450V/750V

0 Review(s)

4,21 € Tax excluded

Livraison : 3 à 6 semaines

Add to cart

ORANGE flexible electric cable sold per meter, comply EVs Orange color multistrand cable Sold by meter (not cut if more than one meter ordered) Cable available in the following sections : : 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm² Standard CE and IEC 245-6 Operating voltage 450VDC / 750VAC Operating temperature -40°C to 70°C

Quick view

12V – 100Ah Lithium battery – PowerBrick+

0 Review(s)

975,24 € Tax excluded

Livraison : 3 à 6 semaines

Add to cart

12V - 100Ah - 1280Wh LiFePO4 battery Nom. voltage : 12.8V 4500 cycles at 80% DoD @ 1C Weight : 13,6Kg Dimensions : 260mm x 168mm x 212mm Continuous discharge : 125A Pulsed discharge (< 30s) : 200A Continuous charge : 100A Serialisable up to 48V Parallelisable up to 10 units Temp. charge : 0°C à +50°C Temp. discharge : -20°C à +60°C ABS IP66...

Quick view

Electric wiring sheath PA

0 Review(s)

1,24 € Tax excluded

Livraison : 1 à 3 semaines

Add to cart

Electric wiring sheath BLACK Available in diameter (inside) from 4,5mm to 30mm Working temperature -55° à +135°C High flexibility RoHs, Certification UL 224 - 300/600V Sold by meter Hellermann Tyton

Quick view

ZAPI controller BLE-4 96V 700Arms

0 Review(s)

1 393,20 € Tax excluded

Livraison : 3 à 6 semaines

Add to cart

ZAPI controller BLE-4 96V 700Arms (2min) Continuous output power 14kW Protection IP65, -40°C à +40°C 11 digital input / 4 analog input (1 for motor temp. sensor) 6 digital output Incrémentale A/B + Hall effect U/V/W + Sin/Cos motor sensor Dimensions: 235mm x 204mm x 103mm Connector TE Ampseal 35 Works with ACIM, BLDC, PMAC, PMSM motors CANopen...

Quick view

ZAPI controller BLE-2 96V 350Arms

0 Review(s)

982,80 € Tax excluded

Livraison : 3 à 6 semaines

Add to cart

ZAPI controller BLE-2 96V 350Arms (2min) Continuous output power 6,5kW Protection IP65, -40°C à +40°C 9 digital inpout / 3 analog input (1 for motor temp. sensor) 2 PWM output Incrémentale A/B motor sensor OR Hall effect U/V/W + Sin/Cos Dimensions: 150mm x 200mm x 79mm Connector TE Ampseal Works with ACIM, BLDC, PMAC, PMSM motors CANopen interface

Quick view

EVEA - Boat throttle - SAIL THROTLLE V2

0 Review(s)

583,20 € Tax excluded

Livraison : 1 à 3 semaines

Add to cart

Electric throttle lever for boat. Compatible with all EVEA V2 PowerBox and SMI-V3 inboard engines This throttle lever combines all the functions necessary to control our electric boat engines. Robust design in powder-coated aluminum and waterproof electrical components that are resistant to seawater.

Quick view

EVEA P14-10D motor / gearbox set

0 Review(s)

1 890,00 € Tax excluded

Livraison : 3 à 6 semaines

Add to cart

EVEA P14-10D complet drivetrain, include a 14kW (35kW max, 80Nm) electric motor + 1:10 gearbox with mechanical differencial integrated. Can be use on light electric véhicles (<1200Kg).

Quick view

EVEA P12-13D motor / gearbox set

0 Review(s)

1 242,00 € Tax excluded

Livraison : 3 à 6 semaines

Add to cart

EVEA P12-13D complet drivetrain, include a 12kW (25kW max, 60Nm) electric motor + 1:13 gearbox with mechanical differencial integrated. Can be use on light electric véhicles (<1200Kg).

NOS PRODUCTS

Quick view

PowerBox 24V - Standard - Liquid

0 Review(s)

1 729,00 € Tax excluded

Livraison : 1 à 3 semaines

Add to cart

The PowerBox V2 is ideally suited for the management of industrial electric motors, whether it is a pump or traction control. It has been developed to perform all the electrical functions that are usually present in the following applications:Forklifts and pedestrian-assisted handling cart Airport Ground Assistance (AGS) including towing tractors...
