ORANGE flexible electric cable sold per meter, comply EVs Orange color multistrand cable Sold by meter (not cut if more than one meter ordered) Cable available in the following sections : : 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm² Standard CE and IEC 245-6 Operating voltage 450VDC / 750VAC Operating temperature -40°C to 70°C
ZAPI controller BLE-4 96V 700Arms (2min) Continuous output power 14kW Protection IP65, -40°C à +40°C 11 digital input / 4 analog input (1 for motor temp. sensor) 6 digital output Incrémentale A/B + Hall effect U/V/W + Sin/Cos motor sensor Dimensions: 235mm x 204mm x 103mm Connector TE Ampseal 35 Works with ACIM, BLDC, PMAC, PMSM motors CANopen...
ZAPI controller BLE-2 96V 350Arms (2min) Continuous output power 6,5kW Protection IP65, -40°C à +40°C 9 digital inpout / 3 analog input (1 for motor temp. sensor) 2 PWM output Incrémentale A/B motor sensor OR Hall effect U/V/W + Sin/Cos Dimensions: 150mm x 200mm x 79mm Connector TE Ampseal Works with ACIM, BLDC, PMAC, PMSM motors CANopen interface
Electric throttle lever for boat. Compatible with all EVEA V2 PowerBox and SMI-V3 inboard engines This throttle lever combines all the functions necessary to control our electric boat engines. Robust design in powder-coated aluminum and waterproof electrical components that are resistant to seawater.
EVEA P14-10D complet drivetrain, include a 14kW (35kW max, 80Nm) electric motor + 1:10 gearbox with mechanical differencial integrated. Can be use on light electric véhicles (<1200Kg).
EVEA P12-13D complet drivetrain, include a 12kW (25kW max, 60Nm) electric motor + 1:13 gearbox with mechanical differencial integrated. Can be use on light electric véhicles (<1200Kg).
The pleasure craft electrification pack ( P4LC 48V 4kW ) is intended to be used when converting pleasure craft categories C - D and sailboats up to 8 meters to electric.DescriptionValueUnitVoltage 48 VdcPower 4 kWRPM 1000 RPMCooler Liquid -Applications BoatSailing shipPleasure -
The pleasure craft electrification pack ( P14LC 96V 14kW ) is intended to be used when converting pleasure craft categories C - D and sailboats up to 8 meters to electric.DescriptionValueUnitVoltage 96 VdcPower 14 kWRPM 1000 RPMCooler Liquid -Applications BoatSailing shipPleasure -
The pleasure craft electrification pack ( P35LC 96V 35kW ) is intended to be used when converting pleasure craft categories C - D and sailboats up to 8 meters to electric.DescriptionValueUnitVoltage 96 VdcPower 35 kWRPM 1000 RPMCooler Liquid -Applications BoatSailing shipPleasure -
Mobile Support for Zivan chargers Compatible with all Zivan chargers : UBC BC1 NG1 NG3 NG5 NG7 NG9 NG9+ SG3 SG6Steel construction with powder coated paint. Cable management support, ergonomic handle.
The PowerBox V2 is ideally suited for the management of industrial electric motors, whether it is a pump or traction control. It has been developed to perform all the electrical functions that are usually present in the following applications:Forklifts and pedestrian-assisted handling cart Airport Ground Assistance (AGS) including towing tractors...
Batteries Management System for 8 to 32 lithium cells:Management of 24V, 36V, 48V, 60V, 72V and 96V batteries (others, contact us) Management of 8 to 32 lithium cells Compatible with all lithium chemistries (LFP, LiFe, LiPo Li-Ion, NMC, LTO, and others) Current and temperature sensors Separate charging and discharging ports CANopen communications...
• Wild input voltage from 12V to 120V• Pulsed air cooling• High liquid cooling flow• Convincing cost-benefit ratio• Automatic or manual fan start up• Voltage converter, fan and pump integrated• Quick connect coupling with dripless
